Aluminum Servo Horn and other hardware is included. 3s Lipo Connector aslo included.
This 14V Series Programmable Servo especially designed for higher voltage application, such as R/C Crawlers, 1/8 1/10 trucks/Cars, Airplanes, Boats, Robots etc...
WARNING: DO NOT USE OVER 14v. YOU WILL VOID YOUR WARRANTY.
Features:
Simplify- 3S Lipo high voltage application, available to connect with battery directly
Smooth- Three ball bearings to make it more powerful and smoother
Powerful- Extra strong steel gears and upgrade structure
Reliable- High quality brushless motor for longer servo life
Waterproof- High accuracy magnetic position sensor, allow to be used in humid or rainy situation
Precision- High precision CNC aluminum machined housing
Programmable- change the firmware for different usage (PowerHobby USB Required (Sold Separately))
Fully Waterproof
Specs:
Operating Voltage: 10v-14v
Operating speed: 0.13 sec/60 @ 11.1V
Operating speed: 0.12 sec/60 @ 12V
Operating speed: 0.10 sec/60 @ 14V
Stall Torque: 48kg - 666 oz-in @ 11.1V
Stall Torque: 57kg - 792 oz-in @ 12V
Stall Torque: 65kg - 900 oz-in @ 14V
Gear: Steel
Motor: Brushless
Size: 40*20*41.5mm (1.57 x 0.78 x 1.63 in)
Weight: 90g
Connector Wire: TYU 300mm / 22AWG
Spline: 25T
